RADIAL / COLUMN DRILLING MACHINES

Radial Drilling SCHLUMBERGER RF6 - Manual raising

RADIAL / COLUMN DRILLING MACHINES

Search

Make

Radial Drilling SCHLUMBERGER RF6 - Manual raising

Type

RF6 - Manual raising

Description - Radial Drilling SCHLUMBERGER RF6 - Manual raising

Denomination
Radial Drilling Machine
Cone
CM4
Spindle speed
from 35 to 1800 RPM
Table size
1000 x 650 mm
Column slide travel along bed
750 mm
Maxi distance spindle nose/table
700 mm (in high position)
Mini distance spindle nose/table
250 mm (in low position)
Various
Manual up/down table + column
Various
Automatic descent
Various
Rotation at 360° on column
Various
Hydraulic column locking
Various
Drilling / tapping function
Equipped with
Lubricant pump
Voltage
380 V
Width
1400 mm
Depth
900 mm
Total height
in low position: 2650 mm
Total height
in high position: 3000 mm
Weight
approx 3 T

Vidéo

Photos Gallery

Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle - Plaque
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle - Armoire électrique
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle - Armoire électrique
Perceuse radiale SCHLUMBERGER RF6 - Montée manuelle - Armoire électrique
